SpeedyBee F405 AIO 40A Bluejay 25.5×25.5 3-6S Flight Controller

SKU: SB-F4-40A-AIO
Add to Wishlist

₹5,899.00

Claim GST input credit with B2B billing. Please enter your GST number at checkout

In stock

Found it cheaper anywhere? Share details, and we’ll make sure you get the best deal.

For bulk orders or B2B inquiries, contact us at sales@uavstore.in

SpeedyBee F405 AIO 40A Bluejay 25.5×25.5 3-6S Flight Controller

Facebook Twitter Youtube Whatsapp Instagram

Any questions, or notice any errors or missing details ?   Let us know !

SpeedyBee F405 AIO 40A Bluejay 25.5×25.5 3-6S Flight Controller

Specification:-

Product Name SpeedyBee F405 AIO
MCU STM32F405
Gyro ICM-42688P
USB Port Type Type-C
Barometer SPA06-003
OSD Supported
Bluetooth BLE Supported, Bluetooth speed enhancement – 2.0
Wireless Flight Controller Firmware Update Supported (no need to press physical BOOT button)
Wireless Download & BlackBox Analysis Not supported
DJI Air Unit Connection Method Supports both 6-pin direct insertion and soldering
6-pin DJI Sky Port Direct Insertion Supported, can directly connect to DJI O3/RunCam Link/Caddx Vista without changing wire order
Flash (for BlackBox) 8MB
Betaflight CC Pads (Camera Parameter Adjustment) Supported
Input Voltage 3S-6S LiPo battery
4V5 Output Two 4V5 outputs; total current 1A
5V BEC Output Three 5V outputs; total current 2A; shared with 4V5
9V BEC Output None (comes with an external BEC module, can switch between 5V and 9V); total current output 2A
MOTOR M1-M4
UART 4 full-function serial ports (UART3, UART4, UART5, UART6 + SBUS[R2])
ESC Telemetry None
I2C Supported
LED Pads Supported, used to control WS2812 LED lights
Buzzer Pads Supported, BZ+ and BZ- pads
BOOT Button Supported, press and hold the BOOT button while powering on to enter DFU mode for firmware recovery
RSSI Pads None
SmartPort Not supported
Supported Flight Controller Firmware BetaFlight (Default), INAV
Firmware Target Name SPEEDYBEE F405AIO
Mounting 25.5 x 25.5mm, 2mm hole diameter
Dimensions 33.0mm (length) x 33.0mm (width) x 8mm (height)
Weight 13.6g (including CNC)
ESC
Product Name SpeedyBee F405 AIO
Input Voltage 3-6S LiPo battery
Continuous Current 40A
Burst Current 45A (10s)
ESC Protocol Supports DSHOT600/300; other protocols may cause severe errors, please use with caution.
Output Voltage VBAT battery voltage (used to power the flight controller)
Current Sensor Supported (Scale = 254, Offset = 0)
Firmware Bluejay JH-40 48kHz
